Stack

Definition

An Abstract Data Types (ADT) where the element that is the last to go in is the first to be removed. This is known as the Last In, First Out (LIFO) principle—similar to a physical stack of dishes.

Operations

The Stack ADT is defined by three primary operations:

Operation	Description
push(element)	Adds an element to the top of the Stack.
top()	Returns the value of the element at the top without removing it.
pop()	Removes the element at the top of the Stack.

---

Implementation via Deque

Just like the Queue, a Deques serves as a perfect backing structure for a Stack. By restricting access to only one end of the Deque, we can implement all Stack features trivially.

C++ Implementation

class Stack {
    private:
        Deque deque; // Backed by a Doubly-Linked List or Circular Array
    public:
        bool push(Data element) { return deque.addBack(element); }
        Data top() { return deque.peekBack(); }
        void pop() { deque.removeBack(); }
        int size() { return deque.size(); }
};

Python Implementation

class Stack:
    def __init__(self):
        self.deque = Deque()
    def push(self, element):
        return self.deque.addBack(element)
    def top(self):
        return self.deque.peekBack()
    def pop(self):
        self.deque.removeBack()
    def __len__(self):
        return len(self.deque)

Implementation Detail

Note that pop() here is void (it only removes). While languages like Java combine removal and return into one step, C++ keeps them separate for architectural clarity.

---

Visualization: The LIFO Process

In the example above:

1. Push: Elements are added to the top (A, then B, then C).
2. State: The Stack is currently [A,B,C], where C is at the top.
3. Pop: The operation removes C first, even though A was there the longest.
4. Result: The new top of the Stack becomes B.

---

Analysis & Patterns

STOP and Think: Could we have used addFront(), peekFront(), and removeFront() instead?

• Yes. For a Stack, it does not matter which end of the backing structure we use, as long as both insertion and removal happen at the same end. This maintains the LIFO property.

---

Applications

The Stack is a foundational tool for managing nested or recursive logic:

• Expression Evaluation: Keeping track of parentheses and operations in complex math (1+(2∗(3+4))).
• Memory Management: The “Function Call Stack” in programming languages tracks active subroutines.
• Graph Exploration: Powering the Depth-First Search (DFS) algorithm.
• Undo Mechanisms: Storing a history of actions where the most recent action is the first to be undone.
