Dynamic Struct

ABSTRACT

Unlike Fixed-Sized Structs, which have a rigid memory footprint determined at compile-time, Dynamic Structs use the Heap to store data of varying sizes. This allows structs to persist beyond the function that created them and handle data that changes in size during runtime.

1. The Power of malloc

The malloc(size_t size) function is the key to dynamic memory.

• Heap Allocation: It returns a pointer to newly allocated memory on the Heap.
• Persistence: This memory does not go away when the function returns. This solves the “Dangling Pointer” problem encountered when returning addresses of stack-allocated local variables.

2. Implementation: From Fixed to Dynamic

In your provided example, we move from a rigid structure to one that can accommodate any number of doubles by storing a pointer to the data rather than the data itself.

Refining the Struct Definition:

typedef struct ListOfDoubles {
    int size;
    double* contents; // Changed from fixed array to a pointer for heap data
} ListOfDoubles;

Revised concat Logic: When concatenating two lists, we calculate the total bytes needed and request that specific amount from the heap.

ListOfDoubles concat(ListOfDoubles d1, ListOfDoubles d2){
    ListOfDoubles result;
    result.size = d1.size + d2.size;

    // Allocate exactly enough space for the combined doubles on the heap
    result.contents = malloc(result.size * sizeof(double));

    for(int i = 0; i < d1.size; i++){
        result.contents[i] = d1.contents[i];
    }
    for(int i = 0; i < d2.size; i++){
        result.contents[i + d1.size] = d2.contents[i];
    }
    return result; // The struct is returned by value, but it carries a pointer to heap data
}

---

3. Memory Lifecycle Comparison

Understanding where your struct data lives is critical for avoiding memory leaks and corruption.

Feature	Fixed-Sized Struct	Dynamic Struct (Heap-based)
Data Location	Stack (inside the struct)	Heap (pointed to by the struct)
Lifetime	Ends when function returns	Lasts until manually free()-d
Flexibility	Limited by MAX_LIST_SIZE	Limited only by available system RAM
Safety	Safer for small, local data	Risk of Memory Leaks if not freed

---

4. Key Takeaways

• Pointer as a Bridge: The struct itself remains small (storing an int and a char*), but it acts as a handle for a much larger, dynamic block of memory on the heap.
• Manual Management: Because malloc memory persists, every malloc must eventually be matched with a free to prevent Memory Leaks (covered in Memory Leak).
